Professional Metallurgical Microscope
The “EXCT-BK5000MT” metallurgical microscope is a professional instrument that produces clear and precise images of metals, ideal for evaluating microstructures in metallurgical testing. Its trinocular head and quintuple nosepiece allow for improved sample viewing. The magnification system, with high-quality eyepiece and objective lens, ensures precise and detailed measurements.
- Categorías: Microscopes, Industrial
- SKU: EXCT-BK5000MT
- Stock: In stock
FEATURES
- Trinocular Head and Quintuple Revolver
- Power supply with rotary potentiometer and 2A fuse ф5×20.
- Up and down support.
- Power switch and fuse on the back.
ACCESSORIES
- 01 Instruction manual.
- 01 Dust cover.
- 01 Blue filter.
- 02 Polarizing lenses.
- 01 Analyzer lens.
TECHNICAL SPECIFICATIONS
| MODEL | EXCT-BK5000MT |
| Eyepiece | WF10X/22mm |
| Metallurgical LWD Infinity Plan Objectives |
LPL5x/0.10 W.D=24.23mm |
| LPL10x/0.25 W.D=18.48mm | |
| LPL20x/0.40 W.D=8.35mm | |
| LPL50x/0.70(S) W.D=1.95mm | |
| Seidentopf Trinocular Head | Inclined 30°, Rotatable 360° |
| Interpupillary Distance: 48mm - 76mm |
